Guillemin fittings are a type of coupling used for connecting hoses and equipment. For liquid, solid or granular products. It is used for both impulsion and suction. These fittings are known for their ease of use and their ability to connect quickly and securely. It is a symmetrical coupling system, which means that both halves are identical.
Guillemin fittings or links have locking rings to connect and secure the other half, one of the two parts must have the ring to be able to secure the connection. Between the two joints of guillemín links to make sealing, it incorporates a gasket, in this case it can be made of various materials to adapt to any application, NBR, Viton, EPDM, PTFE, etc.
Guillemin fittings have a bayonet design that allows for quick and secure connection without the need for special tools. They are available in a variety of materials, such as AISI 316L Stainless Steel (NF A 35.572), Aluminum (A.U5GTY34 “ALUFRAN LABEL”), Bronze (NF A 53.707) and Polypropylene (Reinforced with 30% fiberglass) which makes them makes them suitable for different applications and environments.
It is important to note that Guillemin fittings are compatible with other fittings of the same type, making them easy to integrate into existing systems. They can also be found in different sizes and types of connections, such as male or female threads type BSP ISO 228, which comply with the NFE03.005 a and DIN 259 or NPT standard, or for mounting on tubes and hoses, which allows them to be adapted to specific needs. of each application. They withstand a pressure of 16 bar.
They are often used in industrial applications, such as the transfer of liquids, chemicals and fluids. And they are used for many sectors, chemistry, agricultural industry, tanker transport, mining, food industries, pharmaceutical industry, transport and suction work or delivery of liquids or powdery products, oil industry, fire fighting.
